Revised overview: A fluoropolymer-enhanced powder coating range designed to offer an attractive balance of long-term weatherability, corrosion resistance and application efficiency. Fluorine content and performance level can be tailored to project requirements.
Recommended application fields:
· High-end steel structures, aluminium curtain wall profiles and metal panels
· Metal system doors and windows, railings and architectural elements
Key selling points:
· Long-term exterior performance with 10-15 year project options
· Strong chemical and corrosion resistance
· Compatible with standard powder coating processes
Application Fields
Suitable for a variety of high-end metal substrates, including:
• High-end steel structures
• Aluminum curtain wall profiles
• Metal system doors and windows
• Metal panels
• Metal railings
Technical Specifications
Property | Test | Standard | Performance |
Powder Properties | State in Container | HG/T 2006 | Uniform color, no foreign matter, loose powder |
Residue (125μm) | HG/T 2006 | Fully passable | |
Mechanical Chemical & Durability Properties | Adhesion | ISO 2409 | Grade 0 |
Impact | ASTM D 2794 | 16mm diameter indenter, 2.5±0.3mm depth; no cracks or delamination | |
Cupping Test | ISO 1520 | ≥ 5mm | |
Bending | ISO 1519 | ≤ 5mm; no delamination | |
Condensation | ISO 6270-2 | 1000h, Grade 0 | |
Salt Spray |
ISO 9227 | Aluminum: Acid salt spray, 1000h, Unidirectional corrosion ≤ 2mm | |
Steel: Neutral salt spray, 1000-1500h, Unidirectional corrosion ≤ 2mm with epoxy or electrophoretic primer | |||
Heat and Humidity | ISO 6270 | 1000h, no blistering or peeling | |
Xenon Lamp Aging Test |
GB/T 1865 | Construction materials: 1000h, gloss retention ≥ 90% | |
Automotive industry: 2000h, gloss retention ≥ 75% |
