Rivers JZ Outdoor Durability Polyester Series Powder Coating

Product Description

Product description

Rivers JZ Outdoor Durability Polyester Series is a range of pure polyester powder coatings cured with TGIC for outdoor use. Exhibiting superior weathering resistance, this series serves as an environmentally responsible coating option. It is supplied in a comprehensive range of colors, gloss levels and decorative surface finishes, including gloss, semi-gloss, matte, sand texture and hammer tone effects.

Powder Properties

Chemical type	Polyester TGIC
Particle size	Suitable for electrostatic spray application
Gloss	Subject to specific product
Specific gravity	1.4-1.6 g/cm³ (depending on colour)
Storage conditions	Sealed and stored in a dry, cool place below 30ºC
Shelf life	6 months (<30ºC), 12 months (<25ºC)
Curing schedule (Object temperature)	15 mins at 190ºC or 10 mins at 200ºC or 8 mins at 210ºC
Film thickness	60-80 μm

Test Conditions

All chemical and physical properties shown are laboratory test results obtained under specific conditions (unless otherwise stated) and are provided for coating application reference only. Actual product performance shall be determined according to the final service environment.

Physical property testing：Based on 0.6 mm degreased cold-rolled steel panels

Chemical and durability testing： Based on Q-panel aluminum (A-36)

Corrosion resistance testing： Based on zinc phosphated panels or silane-pretreated Q-panel steel (R-36)

Physical Properties

Test item	Standard	Result
Bend test	ISO 1519	Pass — curvature diameter 4 mm
Dry adhesion	ASTM D3359	Pass — result 5B
Dry adhesion	ISO 2409	Pass — result Grade 0
Cupping test	ISO 1520	Pass 5 mm — no cracking or detachment of coating
Impact resistance (direct impact)	ASTM D2794	>=50 kg·cm
Pencil hardness*	ASTM D3363	H -2H(Mitsubishi pencils)

Chemical / Durability Properties

Test item	Standard	Result
Water fog resistance	ASTM D1735	Pass — 1000 hours, no blistering or gloss loss
Water immersion resistance	ASTM D870	Pass — 240 hours, no blistering or gloss loss
Weatherability	ISO 11341	Pass — 500-1000 hours
Chemical resistance	-	Good (tested with common acids, alkalis and oils at room temperature)

Corrosion Resistance

Test item	Standard	Result
Neutral salt spray (zinc phosphated)	ASTM B117	Pass — 1000 hours
Neutral salt spray (silane pretreatment)	ASTM B117	Pass — 500 hours
